AEC-Q200是车规无源器件应力测试标准，AEC-Q200认证是被动元件汽车级品质认证，被动元器件厂家要进入汽车领域，必需要通过AECQ200测试。广东尊龙凯时人生就是搏检测是专业第三方AEC-Q200认证测试机构，接下来为各人先容AECQ200测试项目。
AEC-Q200 REV D标准TABLE 1界说了AECQ200的所有测试项目及样品数目要求，TABLE 2 - TABLE 14划分针对差别的产品界说了测试项目及测试要求。
| TABLE 1 - QUALIFICATION SAMPLE SIZE REQUIREMENTS 表1-认证测试样品数目要求 | |||||
| Stress 应力方法 | NO. | Note 注释 | Sample Size Per Lot 样品数/批 | Number of lots 批次 | Accept on Number failed 接受标准 |
| Pre-and Post-Stress Electrical Test 应力测试前后电气测试 | 1 | G | All qualification parts submitted for testing | 0 | |
| High Temperature Exposure 高温存储 | 3 | DG | 77 Note B | 1 | 0 |
| Temperature Cycling 温度循环 | 4 | DG | 77 Note B | 1 | 0 |
| Destructive Physical Analysis 破损性物理剖析 | 5 | DG | 10 Note B | 1 | 0 |
| Moisture Resistance 湿度对抗 | 6 | DG | 77 Note B | 1 | 0 |
| Humidity Bias 偏高湿度 | 7 | DG | 77 Note B | 1 | 0 |
| High Temperature Operating Life 高温事情寿命 | 8 | DG | 77 Note B | 1 | 0 |
| External Visual 外观 | 9 | NG | All qualification parts submitted 所有提交认证的产品 | 0 | |
| Physical Dimensions 尺寸 | 10 | NG | 30 | 1 | 0 |
| Terminal Strength 端子强度 | 11 | DGL | 30 | 1 | 0 |
| Resistance to Solvent 溶剂对抗 | 12 | DG | 5 | 1 | 0 |
| Mechanical Shock 机械攻击 | 13 | DG | 30 Note B | 1 | 0 |
| Vibration 振动 | 14 | DG | |||
| Resistance to Solder Heat 抗焊接热 | 15 | DG | 30 | 1 | 0 |
| Thermal Shock 热攻击 | 16 | DG | 30 | 1 | 0 |
| ESD 静电放电 | 17 | D | 15 | 1 | 0 |
| Solderability 可焊性 | 18 | D | 15 each condition 每种条件 | 1 | 0 |
| Electrical Characterization 电气特征 | 19 | NG | 30 Note A 注重事项A | 3 | 0 |
| Flammability 可燃性 | 20 | D | Present certificate of compliance 提供及格证实书 | ||
| Board Flex 板弯曲 | 21 | DS | 30 | 1 | 0 |
| Terminal Strength (SMD) 端子强度（外貌贴装元件） | 22 | DS | 30 | 1 | 0 |
| Beam Load 射束负载（断裂强度） | 23 | DG | 30 | 1 | 0 |
| Flame Retardance 阻燃测试 | 24 | DG | 30 | 1 | 0 |
| Rotation Life 旋转寿命 | 25 | DG | 30 | 1 | 0 |
| Surge Voltage 浪涌电压 | 27 | DG | 30 | 1 | 0 |
| Salt Spray 盐雾测试 | 29 | DG | 30 | 1 | 0 |
| Electrical Transient Conduction 瞬时电传导 | 30 | DG | 30 | 1 | 0 |
| Shear Strength 剪切强度 | 31 | DG | 30 | 1 | 0 |
| Short Circuit Fault Current Durability 短路失效电流长期性 | 32 | DG | 30 | 1 | 0 |
| Fault Current Durability 失效电流长期性 | 33 | DG | 30 | 1 | 0 |
| End-of-Life Mode Verification 寿命终止模式验证 | 34 | DG | 30 | 1 | 0 |
| Jump Start Endurance 助推启动长期性 | 35 | DG | 30 | 1 | 0 |
| Load Dump Endurance 突缷负荷长期性 | 36 | DG | 30 | 1 | 0 |
LEGEND FOR TABLE 1 表1说明
Note:
A For parametric verification data, sometimes circumstances may neccessitate the acceptance of only one lot by the user. Should a subsequent user decide to use a previous user's qualification approval, it will be the subsequent user's responsibility to verify an acceptable number of lots were used.
关于参数验证数据，有时情形可能需要用户仅接受一个批次。若是后续用户决议使用先前用户的资格认证，则后续用户将认真验证使用的批次数目是否可接受。
B Where generic (family) data is provided in lieu of component specific data, 3 lots are required.
若是提供通用（系列）数据取代部件特定命据，则需要3批。
H Required for hermetic packaged devices only.
仅适用于密封包装装备。
L Required for leaded devices only.
仅限含铅装备。
N Nondestructive test, devices can be used to populate other tests or they can be used for production.
无损检测，装备可用于填充其他测试或用于生产。
D Destructive test, devices are not to be reused for qualification or production.
破损性试验，装备不得重复用于判断或生产。
S Required for surface mount devices only.
仅适用于外貌装置装备。
G Generic data allowed. See Section 2.3.
允许通用数据。见第2.3节。
